DSC HSM2208 PowerSeries Pro Neo Low Current Output Security Module

The DSC HSM2208 PowerSeries Pro Neo Low Current Output Security Module is a low current output module for any PowerSeries Neo security system.

Main Features

• The HSM2208 provides 8 programmable low voltage outputs
• Connect up to 16 modules per system
• Provides 8 low current (50 mA) programmable outputs

Specifications:

Ordering Information: ….…..HSM 2208 Low Current PGM Expander

Dimensions: … ……………… 45mm x 92mm (1.12/16” x 3 5/8”)

Board Current Draw: ……. 60mA (Max)

Voltage: ………………………..12 VDC Nominal

Operating Environment:….-10°C to 55°C (14°F to 131°F)

Relative Humidity: ………..  5 to 93%

Approvals: Please refer to www.dsc.com for the most current approval listings.

Compatibility: The HSM2208  is compatible with all PowerSeries Neo control panels
