Honeywell Home 5800PIR-OD2 Outdoor Wireless Motion Detector

The Honeywell Home 5800PIR-OD2 Wireless Outdoor Motion Detector is an AA lithium battery powered wireless outdoor motion detector intended for use with Honeywell Home alarm systems that support 5800 Series wireless devices. The 5800PIR-OD2 is an ideal solution  for outdoor sensing needs in difficult to wire locations— avoiding the costs and time to trench hardwired solutions. It’s perfect for both residential (activity monitors, e-mail alerts, turning on video cameras) and commercial (protecting copper theft, utility and electrical substations, cellular sites, commercial buildings, car lots and more) applications.

The Honeywell Home 5800PIR-OD2 Wireless Outdoor Motion Detector consists of two passive infrared (PIR) sensors that must both be tripped to declare an alarm, providing immunity to false alarm sources, pets and other animals. These sensors can be adjusted to alter the detection range. The transmitter can send alarm, tamper and low battery condition messages to the alarm panel.

FEATURES AND BENEFITS:

• Discriminates both large and small animals to reduce false alarms
• Adjustable range patterns from 8′ up to 40′. The 90º pattern can also be adjusted throughout a 180º field of view by simply swiveling the housing.
• Battery saving feature allows you to select five seconds of inactivity (for higher security requirements or where up-to-date information is critical) or 120 seconds of inactivity after alarm (for initial notification)
• Immune to bright lights from head lamps, sunlight and other light sources that typically generate false detections
• Full Supervision – The 5800PIR-OD2 is fully supervised to monitor for low battery, case tamper and trouble conditions
• Versatile Mounting – Whether you choose to affix the detector to a wall or a fence post, mounting is simple
• Tamper Protection – The detector has a built-in tamper switch that can communicate back to the control panel in the event it is removed from the

Honeywell Home 5800PIR-OD Data Sheet
